Brother MFC-8220 Service Manual

APPENDIX 3 FIRMWARE SWITCHS (WSW)
A-38
WSW37 (Function setting 15)
Selector
No.
Function Setting and Specifications
1
Printout of the stored image data of
an unsent document onto the error
report
0: No 1: Yes
2
Erasure of the stored image data of
an unsent document at the time of
the subsequent in-memory
message transmission
0: No 1: Yes
3
|
8
Not used.
l Selector 1: Printout of the stored image data of an unsent document onto an error report
This selector determines whether or not the 1st-page image data of a document will be
printed out onto the error report if the document image data stored in the temporary memory
cannot be transmitted normally.
l Selector 2: Erasure of the stored image data of an unsent document at the time of the
subsequent in-memory message transmission
If in-memory message transmission fails repeatedly when selector 1 is set to "1," the
temporary memory will be occupied with image data. Setting selector 2 to "1" will
automatically erase the stored 1st-page image data of an unsent document at the time of the
subsequent in-memory message transmission only when recording paper or toner runs out.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
