Brother MFC-8220 Service Manual

APPENDIX 3 FIRMWARE SWITCHS (WSW)
A-46
WSW46 (Monitor of PC ON/OFF state)
Selector
No.
Function Setting and Specifications
1
2
Monitoring the PC ON/OFF state
No. 1 2
0 0 : Disabled
0 1 : Monitor SELECT IN
1 0 : Monitor STROBE
1 1 : Monitor both SELECT IN and
STROBE
3
Parallel port output pins kept at high
level
0: Enabled 1: Disabled
4
Scanned garbage correction
processing
0: ON 1: OFF
5
|
8
Not used.
NOTE:
• Selector 3 is applicable only to models equipped with a parallel interface.
• Selectors 6 through 8 are applicable only to models equipped with a flat-bed scanner.
l Selectors 1 and 2: Monitoring the PC ON/OFF state
For the related functions, refer to WSW36, selectors 2 and 3.
l Selectors 3: Parallel port output pins kept at high level
Setting this selector to “0” will keep all parallel output pins of the facsimile equipment at high
level. Use this setting if Resource Manager (bundled with MFC models) installed to Windows
NT running on the connected PC fails to monitor the power ON/OFF state of the facsimile
equipment.
WSW47 (Extending the closing state of the FAX line)
Selector
No.
Function Setting and Specifications
1
|
7
Not used.
8
Switching of USB 2.0 High-
Speed/USB 1.1 Full-Speed
0: Auto (Automatic switching)
1: USB 1.1 Full-Speed is set.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
