APPENDIX 3 FIRMWARE SWITCHS (WSW)
A-40
WSW39 (Function setting 17)
Selector
No.
Function Setting and Specifications
1
|
4
First transmission speed choice
for fallback
No. 1 2 3 4
No. 5 6 7 8
0 0 0 0 : 2400 bps
0 0 0 1 : 4800 bps
0 0 1 0 : 7200 bps
0 0 1 1 : 9600 bps
0 1 0 0 : 12000 bps
0 1 0 1 : 14400 bps
0 1 1 0 : 16800 bps
0 1 1 1 : 19200 bps
5
|
8
Last transmission speed choice
for fallback
1 0 0 0 : 21600 bps
1 0 0 1 : 24000 bps
1 0 1 0 : 26400 bps
1 0 1 1 : 28800 bps
1 1 0 0 : 31200 bps
1 1 0 1 : 33600 bps
1 1 1 0 : 33600 bps
1 1 1 1 : 33600 bps
NOTE:
WSW39 takes effect only in V. 34 mode. For the transmission speed setting in other modes,
refer to WSW19.
l Selectors 1 through 8: First and last choices of transmission speed for fallback
These selectors are used to set the modem speed range. With the first transmission speed
choice specified by selectors 1 through 4, the machine attempts to establish the transmission
link via the modem. If the establishment fails, the machine automatically steps down to the
next highest speed and attempts to establish the transmission link again. The machine
repeats this sequence while stepping down the transmission speed to the last choice
specified by selectors 5 through 8.
If the modem always falls back to a low transmission speed (e.g., 24,000 bps), set the first
transmission speed choice to the lower one (e.g., modify it from 31,200 bps to 26,400 bps) in
order to deactivate the high-speed modem function and reduce the training time for shorter
transmission time.
WSW39 will be limited by selectors 3 through 8 of WSW40.
