Brother MFC-8220 Service Manual

MFC-8220
SERVICE MANUAL
6-57
10.8 Windows
®
95/98/Me/2000/XP/NT 4.0 Peer to Peer Print (NetBIOS)
Troubleshooting
If you are having trouble printing on a Windows
®
95/98/Me/2000/XP/NT 4.0 (or later) Peer to
Peer network (NetBIOS), check the following:
(1) Make sure that the Brother NetBIOS Port driver is securely installed and configured
according to the Windows
®
95/98/Me/2000/XP/NT 4.0 Peer to Peer (NetBIOS) chapters.
You may find that during the installation of the port driver, the screen that prompts you for
a Port name is not displayed. This happens on some Windows 95/98/Me/2000/XP/NT 4.0
computers. Press the ALT and TAB keys to make it appear.
(2) Make sure that the print/fax server is configured to be in the same workgroup or domain
as the rest of your computers. It may take several minutes for the print/fax server to
appear in the network neighborhood.
10.9 Brother Internet Print (TCP/IP) Troubleshooting
(1) The first step in troubleshooting is to make sure that you have a valid E-mail connection
on both the sending PC and the receiving print/fax server. Try sending an E-mail
message from the PC to a user at the remote site who can receive mail via the POP3
server. If this does not work, there may be an E-mail configuration problem on the PC, on
the local E-mail server, or on the remote POP3 server. Double check to make sure that
the E-mail parameters that you configured on the PC and on the remote print/fax server
match those that are configured on the E-mail servers.
(2) If you can print small files OK but are having problems printing large files, the problem
may be in the e-mail system. Some e-mail systems have difficulties printing large files. If
the file does not reach its destination intact, then the problem is with the E-mail system.
(3) You can also enable the partial e-mail print facility on your client PC, this will split the e-
mail up into fragments which should then not overwhelm your e-mail server. To do this,
select the property dialog of the Brother Internet Print Port.
10.10 Windows
®
95/98/Me/2000/XP IPP Troubleshooting
Want to use a different Port number other than 631
If you are using Port 631 for IPP printing, you may find that your firewall may not let the print
data through. If this is the case, use a different port number (port 80), or configure your
Firewall to allow Port 631 data through.
To send a print job using IPP to a machine using Port 80 (the standard HTTP port) enter the
following when configuring your Windows
®
2000/XP system.
http://ip_address/ipp
“Get More Info” option in Windows
®
2000 not working
“Go to Printer’s Web site” in Windows
®
XP not working
If you are using a URL of:
http://ip_address:631
or http://ip_address:631/ipp,
the Get More Info option in Windows
®
2000 or the Go to Printer’s Web site option in
Windows
®
XP will not function. If you wish to use the Get More Info or the Go to Printer’s
Web site option use the following URL:
http://ip_address
This will then force Windows
®
2000/XP to use Port 80 to communicate with the Brother
print/fax server.
Windows
®
95/98/Me clients not able to get the driver from a Windows
®
2000/XP system.
You must be using version 4.0 or later of Internet Explorer and the Microsoft Internet Print
Services software must be installed on your client computers.

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
