6. Soldering irons
When soldering is performed manually using lead-free solder, a soldering iron that has
little reduction in its temperature needs to be used. This refers to a soldering iron that
has a smaller degree of decrease in the temperature at the soldering iron's tip, such as
when the soldering iron is applied to the base metal or solder is supplied, and the
temperature is soon returned to the specified temperature.
With soldering operations using lead-free solder, the requirement for the temperature of
the soldering iron's tip is the same as that for conventional solder, however, the melting
point of lead-free solder is higher than that of conventional solder so productivity will
decrease with conventional soldering irons.
Some tool manufacturers sell soldering irons designed for lead-free solder and that can
maintain the productivity of the soldering operations.
The soldering irons used at BIL are model no. 941 manufactured by HAKKO and M6-
SIC-40 manufactured by BONKOTE. The prices of these soldering irons for use with
lead-free solder are three to four times higher than those for conventional soldering irons
with a temperature controller built in.
7. No mixing of different solders
When repairs are made on a PCB with an "LF" indication on it, lead-
free solder with the same metal composition, which is expressed by
the digit following "LF", must be used on a single PCB. For a PCB
with an "LF" indication on it, neither tin-lead solder nor lead-free solder
with a different metal composition must be used.
Compatible solder for each countries are listed below. Solders are freely available from each
manufacturer. Visit the web site below for more detail.
Countries Manufacturer Origin Name Web site
For Japan, UK,
Finland,
Germany,
France,
Sweden
ALMIT JAPAN KR-19 SH RMA
LFM-48
http://www.almit.com
For World wide
except
Australia, New
Zealand
KESTER U.S.A. KESTER245
KESTER285
http://www.kester.com
For Worldwide AIM CANADA CASTIN RMA2 http://www.aimsolder.co
m

Brother MFC-8220 Specifications

General

Type	all in one
Tray Capacity	250
Automatic Document Feeder Capacity	30 sheets
Paper Size	letter, legal, a4, b5, a5, b6, a6, exe
Paper Handling	up to 250 sheets
Mono Print Speed	21 pages per minute
Print Resolution Mono	up to 2400 x 600
Maximum Number of Pages Per Month	up to 20, 000
Scanner Type	sheetfed
Scan Resolution	up to 300 x 600
Copier Resolution Mono	up to 600
Fax Function	yes
Cartridges	n/a
Number Of Cartridges	2
Internal Memory	yes
Network	not applicable
Connectivity	parallel, usb 2.0
OS Compatibility	pc: windows 95, 98, 98se, me, nt workstation 4.0, 2000 professional or xp, mac: os 8.6 to 9.2, os x 10.1, 10.2.1 to 10.3 or later, available usb 2.0 or parallel port
Mobile Devices Connection	no

Weight and Dimensions

Height	13.2 inches
Width	17 inches
Net Weight	25.6 pounds
