CHAPTER 2 INSTALLATION AND BASIC OPERATION
2-12
NOTE:
If you are sharing one phone line with an external telephone, connect it as shown below.
Fig. 2-20
NOTE:
- If you are sharing one phone line with an external telephone answering device, connect it as
shown below.
- Please set the receive mode to External TAD.
- For more details, see “Connecting the MFC” in Chapter 1 of the User’s Guide.
Fig. 2-21
TAD
TAD
To Next Page
