Burford 2000 - Main Enclosure Components

Parts and Drawings 187
 Main Enclosure
FLTR1
LINE FILTER
TB3
TERMINAL BLOCK
CAP2 BRUSH
MOTOR CAPACITOR
PE GROUND
CR2
CR5 CR6
CR4
CR3
CAPACITOR
CAP1
CR1 SERVO ENABLE
CONTACTOR
DISC1 MAIN
DISCONNECT
GROUND
TERMINALS
FUSE FU1,
FU2, FU3
CIRCUIT BREAKERS
CB3, CB4
CR3
CR5 PDS EXTERNAL
COUNTER RELAY
REC1 BRIDGE
RECTIFIER
PSM1
POWER SUPPLY
PC2 AUXILIARY
BOARD (C01267)
PC3 CPU
BOARD (CO1410)
PC1 FTB
(C01299)
SEVEN
SEGMENT LED
CRE1 BRUSH
MOTOR RELAY
DIAGNOSTIC
LEDS
SERIAL
PORT J1
CRM MAIN POWER
CONTACTOR
CR2 BAGGER
ENABLE RELAY
T1
TRANSFORMER
