Parts and Drawings 189
Main enclosure relays
CRM, (C07245): Latches in main power.
CR1, (C07245): Connects 34VDC motor power to Aux board.
CR2, (C01269-003): Latches the bagger enable signal.
CR5, (C01269-003): Package Detection System, external counter contacts.
CRE1, (C05138): Latches in Brush Motor.
Field termination board relays
CR2, (C01270): Servos Enabled Relay, energizes coil of CR1 (panel relay).
CR3, (C01269-003): Brush/Belt Relay, bagger energizes this relay to start and stop
brushes and belts.
CR4, (C01270): Bagger Enable Relay starts and stops bagger run circuit.
CR5, (C01270): Horn Relay, controls audible alarm.
CR6, (C01270): Counter Relay, controls external counter output.
Auxiliary board relays
CR1: Run Circuit Relay, operator “RUN” button latches in this relay.
CR9: CPU Status Relay, CPU energizes this relay if it is ready to control the motors.
