Burford 2000 - Gathering Brush Power Diagram

Parts and Drawings 191
 Gathering Brush Power Diagram
R4
AC AC
+5V +12V
56
B
A 4 3
9
23
9
23
22
22
17
68
22
1
2
23
17
935
L.E.D.
D28
BRUSHES/
BELTS RELAY
VAC/VDC CUSTOMER
SIGNAL FROM
BAGGER
SS1
BRUSH/BELT
AUTO
ON
J27 BAGGER CLUTCH
9
40
43
FIELD TERMINATION
BOARD
BAGGER
ACTIVE SIGNAL
TO CPU
LINE
NEUTRAL
110VAC
SOLID STATE
RELAY
BRUSH
MOTOR
MTR5***
CB6
CB3
CRE1
CR3
CR3*
* LOCATED ON MAIN PANEL
** SUP1 INSTALLED WHEN CR3 (FTB) = 12V COIL,
NOT INSTALLED WHEN CR3 (FTB) = 120V COIL.
*** 3A CB AND CAPACITOR LOCATED INSIDE BRUSH MOTOR.
SUP1**
GATHERING BRUSHES POWER
AND CONTROL CIRCUIT
