105
Auxiliary functions
Example of a programmed characteristic
Valve stroke [%]
(POS)
Standard signal [%]
(CMD)
10
20
30
40
50
60
70
80
90
100
10 20 30 40 50 60 70 80 90 100
0
4 ... 20 mA
0 ... 20 mA
0 ... 10 V
0 ... 5 V
Figure 54: Example of a programmed characteristic
In the section “Tables for customer-specific settings” in chapter “42.1. Settings of the freely program-
mable characteristic” there is a table in which you can enter your settings for the freely programmable
characteristic.
english
Type 8792, 8793
