Operating structure / Factory settings
CAL.USER
OUT BIN 1
OUT BIN 2
POS.Dev
POS.Dev
FAILURE
Limit 0.0 %
Limit 100.0 %
Deviation 1.0 %
Deviation 1.0 %
FAILURE
normally open
normally open
POS.Lim-1
POS.Lim-2
Safepos
Safepos
Remote
Remote
Tune.Status
Tune.Status
ERR.SP/CMD
11)
ERR.SP/CMD
11)
ERR.PV
12)
ERR.PV
12)
DIAG.State-1
DIAG.State-2
OUT.type
OUT.type
OUT SPEC
OUT SPEC
normally closed
normally closed
FUNC.CHECK
FUNC.CHECK
MAINTENANCE
MAINTENANCE
1,0 %
1,0 %
0 %
100 %
Figure 107: Operating structure - 8
11) only if fault detection is activated for the input signal
(SIG.ERROR
→ SP/CMD Input or PV-Input → Error on)
12) Only process controller Type 8793 and if fault detection is activated for the input signal
(SIG.ERROR
→ SP/CMD Input or PV-Input → Error on)
