11.4.2 BA ROLLANT 240 - 250 - 254 - 255 - 000 299 119 5
CLAAS COMMUNICATOR
Meaning of the symbols:
Note!
The figure 100 below the baler symbol informs
that a fault has occurred: e.g., the bale could be
blocked on the bale chute etc.
(Fig. 1, 3)
3
R
4
No twine on left hand side
No twine on right hand side
No net
Fault in the bale chute
Fault at switch twine wrapping
System fault
