HelixNet | User Guide
1.5 System Resource
A HelixNet system/Link Group will support up to 64 endpoints.
Endpoints consume system resources depending on the number of audio paths the endpoint
contains and may include: user stations, assigned interface ports, program audio inputs, LQ,
Agent-IC and SIP accounts.
Exceeding the system endpoint limits will cause a sluggish system response.
1.5.1 Conserving system resource
In larger systems it is recommended to balance the loading of endpoints on the HMS-4X Main
Stations in the Link Group. LQ interface ports and LQ Agent-IC, IVC and SIP accounts load the
resources of the system's Link Master.
HRM-4X Remote Stations include multiple audio interfaces which can be assigned to the system's
channels. When assigned to channels, these use resources. The Remote Station allows you to
disable the unit's program audio input as well as to configure the stage announce output for local
use. In this way you can conserve system resources in larger systems.
1.5.2 System resource meter
There is a resource meter on the main station device icon. This is found in the Overview page of
the CCM. Hover your mouse over this icon to see how many system resource units are in use.
System Resource Units (up to 70)
Color Indication Units
Green ≤ 59 Within system limits
Amber 60 - 63 Approaching limits
Red ≥ 64 Exceeding limits
