Clear-Com HelixNet Partyline - Beltpack (HXII-BP-X4)

HelixNet | User Guide
Specification Description / value
Frequency response 40Hz - 10kHz ±3dB
Noise <-65dBu (@ max gain)
Headphone limiter -0dBu (selectable)
20.7.4 Power Requirements HBP-2X Beltpack
Specification Description / Value
Power requirement 4W
DC Voltage range 3- - 60V
20.7.5 Environmental
Specification Description / value
Temperature 0˚C - 40˚C (32˚F - 104˚F)
Humidity 0 - 90% relative humidity
20.8 Beltpack (HXII-BP-X4)
20.8.1 20.7.1 Connectors
Specification Description / value
XLR Powerline 3-pin XLR (female).
LAN/PoE RJ45 etherCON
Headset 4-pin XLR–M
USB Micro-AB
20.8.2 Microphone Pre-Amplifier
Specification Description / value
Headset Mic impedance: 200Ω (Dynamic)
Headset Mic Voltage 1.7V (Electret selectable)
Routed to 4-wire output @ 0dBu out:
Page 243
