is established, the icon will show solid.
5.6.5 Viewing the Module Settings: Version Information
The software (firmware) for the ports on the interface module must match that on the HelixNet
Main Station itself.
Note: Ethernet and fiber option modules do not contain software.
To check the software version for the Main Station and each port on the interface module:
1. In Menu mode, select Administration > Software > Current.
2. In the fourth menu, use the rotary control to scroll the displayed software versions.
3. The software versions for each port are listed under Snx, where n indicates the slot number,
and x indicates port A or port B.
The software versions for the two processors in the Main Station (Main Station and IV-Router) are
listed under MS and IVR respectively.
5.7 Administration
5.7.1 In Menu mode > Administration, you can:
l Update and view the current software (firmware)
l Upgrade and view the current licence (how many channels are available)
l Reset the Main Station and audio configuration
l Reboot the Main Station
l Get system logs for diagnostic purposes
l See the CCM login credentials (including password). This option is only available if you
have either not changed the CCM password or reset the main station to factory default
Page 97
