Clear-Com HelixNet Partyline - Two-Wire Module (HLI-2 W2)

HelixNet | User Guide
20.1.8 Mains Power
Specification Description / value
Input voltage range 100 – 240VAC
Input frequency range 50 – 60Hz
Input power <=250W
Input power connector IEC-C14
Practical power range
l Power (normal): 80 - 250W
l BTU (normal):275 - 850 BTU/hr
l Dependent on hosted modules and connected
beltpacks
20.1.9 Environmental
Specification Description / value
Temperature 0˚C - 40˚C (32˚F - 104˚F)
Humidity 0 - 90% relative humidity
20.1.10 Dimensions and Weight
Specification Description / value
Dimensions 19in W x 1.75in H x 13in D (483 mm x 44 mm x 330 mm)
Weight 5.83lbs. (2.65kg)
20.2 Two-Wire Module (HLI-2W2)
20.2.1 Connectors
Specification Description / value
Intercom line (2) 3-Pin XLR-F
Page 231
