23.4 Cable Connections
The diagrams on the following pages reference the following labels and notes.
Label Manufacturer Part Number Description
Clear-Com HMS-4X HelixNet Main Station
Belden 8760,9207
Or
9463F
18 or 20 AWG twisted pair cable
terminated with 3-pin XLR
Middle Atlantic (or
equivalent)
CH-1 1 RU shielded chassis
Neutrik (or equivalent) NC3FD-L-B-1 3 pole female chassis mount
Neutrik (or equivalent) NC3MD-L-B-1 3 pole male chassis mount
Neutrik (or equivalent) NA3MDF 3 PIN XLR M-F FEED THRU
ADAPTER
Belden (or existing
cabling)
1351A or 1533P 24 AWG, shielded cat 6 cabling
Belden 8760,9207 or
9463F
XLR3 M-F patch cord
Belden 8760,9207 or
9463F
18 or 20 AWG twisted pair cable
