HelixNet | User Guide
6.2.4 Settings the RMK (Remote Mic Kill) Key
To configure the RMK settings, see Setting the RMK (Remote Mic Kill) key.
Note: This does not apply to the Remote Station in expansion panel mode.
6.2.5 Setting Display Screen Brightness
To configure the display screen brightness, see Setting display screen brightness.
6.2.6 Setting Key Brightness
To configure the key brightness settings, see Setting key brightness.
6.2.7 Setting the Screensaver
To configure the screensaver settings, see Setting the screensaver.
6.3 Configuring the Channel settings
6.3.1 Editing the Channel label
To edit the Channel label, see Editing the Channel label.
6.3.2 Assigning the Program Listen to a Channel
To assign the program listen to a Channel, see Assigning the Program Listen to a Channel.
6.3.3 Assigning a GPO Relay to a Channel
You can assign a relay that is triggered on receiving a call or detecting a talk on a Partyline
Channel. See Assigning a GPO relay to a Channel.
6.4 Configuring the Control I/O
The Control I/O connector on the rear panel allows you to connect one relay output or one opto
input and control them through the Remote Station keysets:
I/O
type
Description
Opto
inputs
Opto inputs enable you to connect a foot switch or other control device and use it to
trigger Call or Talk functions. Selecting the 'mic' option here allows the user to utilize a
footswitch to enable talking to the pre-latched channels on the user station - hands
free.
Relay
outputs
Relay outputs enable you to use Call or Talk keys to trigger any external device that
accepts a standard contact closure (such as a theater curtain or an On Air light).
Page 109
