2.6 HBP-2X Beltpack
For information about the HXII-BP-X4 Beltpack, see HXII-BP-X4 Beltpack
2.6.1 HBP-2X User Controls (Front and Side View)
Note: The beltpack has two Keysets, each containing one Call button (E) and one Talk button
(F).
Key to HBP-2X user controls (front and side view)
Feature Description
Menu key. Press firmly to enter Menu mode (see also D,E ). To exit Menu mode,
press the Menu key again.
The display screen times out of Menu mode and displays the Channel label(s) if no
key is pressed for 20 seconds.
USB 2.0 (Micro-AB) connector. Used for the USB light flasher feature. See Call a
beltpack using the USB flasher feature
Page 40
