20.4.2 Dimensions and Weight (HLI-FBS)
Specification Description / Value
Dimensions
2.2 x 7.4 x 1.5 inches
(57 x 187 x 39mm) (HxWxD)
Weight 13oz (0.35kg)
20.5 Remote Station (HRM-4X)
20.5.1 20.4.1 Connectors
Specification Description / value
Intercom Powerline Outputs Two 3-pin XLR. One male and one female.
Headset 4-pin XLR–M
Gooseneck mic 3-pin Tuchel
USB USB Type A
Program 3-pin XLR–F
SA (Stage Announce) 3-pin XLR–M
Hot Mic / IFB Interface 1/4 in. (0.64 cm) phone jack
Control and audio input/output 9-pin D-type
DC power 3-pin KPJX-PM-3-S
20.5.2 Microphone Pre-Amplifier
Specification Description / value
Headset Mic impedance: 200Ω (Dynamic)
Headset Mic Voltage 1.7V (Electret selectable)
Limiter +23dB
Routed to 4-wire output @ 0dBu out
Mic gain 60dB (dynamic) 45dB (electret)
