Main Station/Remote Station display icons and indicators
Limiter LIM Appears on the Main Station, Remote Station, Speaker
Station and beltpack when the headset limiter is enabled.
Expansion Appears on the Main Station and Remote Station when
the device is part of an Expansion Group.
Warning Appears on the Main Station, Remote Station, Speaker
Station and beltpack when something is wrong. Warning
messages can be accessed in the Diagnostic menu.
Key to Main Station: rear panel
Feature Description
Power supply with metal cable clip. The power supply operates at 100 - 240
VAC / 50-60Hz / 250 watts / T 3.15A H 250 V.
Control I/O (25 way female D-type). Use to connect up to 4 relay control outputs
and 4 optically isolated control inputs, see Configuring the Control I/O)
