Key to Speaker Station front panel
Feature Description
Tilt adjustable display screen. The following default information is displayed:
l The Channel label.
l The Channel listen (volume) level.
For a full description of the display screen information, see (link…)
In Menu mode, the display screens display the two levels of menu. The menu
hierarchy proceeds left to right:
l The top level menu is presented in the first screen (furthest left on the front
panel).
l The lower level menu is presented in the second screen.
If the display is in Menu mode, the display screen times out of Menu mode and
displays the Channel label if no key is pressed for 20 seconds.
For more information about Menu mode, see Using the Menus
Rotary control. Turn to increase or decrease the listen volume level for the
Channel. Also, push the control to mute or unmute audio level. In Menu mode, use
the control to scroll menu items. To select menu items, press the control.
