HelixNet | User Guide
Key to Remote Station: rear panel
The audio connections in this connector are wired directly to the SA and program
connectors. Only one or the other can be used at one time.
SA [Stage Announce] line out (3-pin female XLR).
Pin Function
Pin 1 Ground
Pin 2 Positive
Pin 3 Negative
Program Input (3-pin m XLR).
Pin Function
Pin 1 Ground
Pin 2 Positive
Pin 3 Negative
Hot Mic output. This connection is a 1/4-in (0.64 cm) phone jack. It provides an
output signal from the selected headset or panel microphone. The Hot Mic output is
always live. Audio from the mic is routed through the Hot Mic output even if the mic
is inactive (off).
Pin Function
Tip Mic
Ring IFB mute signal
Sleeve Ground
