Label Note
Wire in accordance with Table 245
Equipment rack, breakout box chassis and patch panel must be connected to safety
earth
Connect up to 32 wall plate locations to patch panel with individual CAT 5 cables
If multiple wall plates are co-located at a remote location, daisy chain their wiring at
the remote location and connect a single CAT 5 cable from the remote location back
to the patch panel
Use short length, high quality XLR patch cords with shielded connectors
Do not patch between separate power lines
Assemble item 6 to panel with male connectors to front
