HelixNet | User Guide
Specification Description / value
Frequency response 20Hz - 10kHz ± 3dB
Distortion <0.2% THD @ 1kHz
Noise <-65dBu
20.1.5 Stage Announce Outputs
Specification Description / value
Maximum level before clipping 18dBu
Nominal output level 0dBu (selectable)
Output impedance <= 100Ω
The following specified for a route from a dynamic headset
Frequency response 300Hz – 12kHz ± 3dB
Distortion <0.1% THD @ 1kHz
Noise <-55dBu
20.1.6 Hot Mic Output
Specification Description / value
Maximum level before clipping 12dBu
Nominal output level 0dBu (selectable)
Output impedance <= 100Ω
The following specified for a route from a dynamic headset
Frequency response 300Hz - 12kHz ± 2dB
Distortion <0.2% THD @ 1kHz
Noise <-55dBu
20.1.7 Ethernet
Specification Description / value
Fast Ethernet standard 100BaseT only, Auto MDIX
Page 230
