HelixNet | User Guide

Key to HXII-BP-X4 user controls (base view)

Feature Description

Line (Digital Partyline) (3-pin female XLR connector).

Pin Function

1 Ground

2 +30V DC and Audio

3 -30V DC and Audio

etherCon connector. Used for Power over Ethernet (PoE).

Pin Name Function

1 TX+ Transmit Data+

2 TX- Transmit Data-

3 RX+ Receive Data+

4 n/c Not connected

5 n/c Not connected

6 RX- Receive Data-

7 n/c Not connected

8 n/c Not connected

When using PoE, the beltpack draws 4 Watts from the PoW switch.
