The following RF related parameters are NOT synchronized between Master Unit and Remote Unit.
Therefore, some MU and RU RF parameters MUST be set individually or using the Batch Setting. The
easiest method is to use <Device - Batch Setting>. See Figure 150 for more details.
Table 22: Commissioning Fiber DAS – Parameters NOT Synchronized between Master and Remotes
Parameter
Function
Batch Setting
RF Switches
Control RF ON/OFF individually for each
MU/RU
Main Menu - Batch Setting
Downlink Output ATT
Control DL Output Power individually for
each MU/RU
Main Menu - Batch Setting
UL Channel Target Power
Setting
Control CH UL Target Power individually for
each MU/RU
Main Menu - Batch Setting
UL Channel Individual Gain
Setting
Control CH UL Gain individually for each
MU/RU
Main Menu - Batch Setting
UL Mute SW
Control Mute SW ON/OFF individually for
each MU/RU
Main Menu - Batch Setting
UL Mute Threshold
Control Mute Threshold ON/OFF individually
for each MU/RU
Main Menu - Batch Setting
UL Gain Limit (LNA Bypass)
Control <UL Gain Limit> individually for each
MU/RU
Main Menu - Batch Setting
Figure 150: Commissioning Fiber DAS – Batch Settings for MU and RUs
