1.14 V3 RU MECHANICAL SPECIFICATIONS
Dimensions, H x W x D
mm / in
330 x 490 x 199 / 13.0 x 19.3 x 7.8
Weight without bracket, (Weight of Bracket)
kg / lbs
25 / 55.1 (1.81 / 4.0)
Power Supply Input
VAC
100-240V / 50-60Hz / 4.5A Max
VDC
+51.2V / 8A Max (Does NOT Support Negative DC Source)
DC Output Voltage to External Device, Nominal
VDC
+51.2VDC (1 Port), +28VDC (2 Port)
External Device Maximum Power Draw
W
105
Maximum Charging Current
A
5
Power Consumption
Single Band
W
<75 (27dBm)
<90 (33dBm)
Dual Band
<85 (27dBm)
<100 (33dBm)
Enclosure Cooling
Convection
Heat Dissipation
BTU/Hr
<480 (with Remote Unit only, 2A Charging) <580 (Full Load)
Main RF Connectors / RF Test Port
N-F (MT) / SMA-F (MT-Test), -28 (+/-4) dB coupling
Dry Contact Alarm Visual Annunciation
Dry Contact Alarm LED 1-8, ALM, RUN (LED test supported)
Dry Contact Alarm Audible Annunciation
Buzzer (Mute and Lamp Test supported)
Communication port
RJ45 (OMT)
Dry Contact Alarm Output
8
External Alarm Input
5 (#5 is pre-configured for Door Open Alarm)
Reserved Knockouts
3/4-inch hole x 1, 1/2-inch hole x 3, 1-inch hole x2
Operating Temperature and Humidity
o
F (
o
C)
-40 to 131 (-40 to +55),  95%
Environmental Class
UL50E Type 4 / NEMA 4
MTBF
Hr
100,000
