16. Scan to Identify Connected
System Devices
⚫ Navigate to <Dashboard> and run a Scan. Wait a few minutes for all
the system devices to be identified and shown in the system tree.
Refer to section 3.15
17. Run System Isolation Detection
Process
⚫ Measures the isolation between the donor antenna and service
antenna branches. Users can use the onboard measurement tool or
enter a manual measurement. Refer to section 3.26
18. Set RU Target Power, Gain,
Squelch, and Advanced Features
⚫ Set the RU DL and UL Channel Target Powers
⚫ Set the RU UL Gains
⚫ Set the RU UL Squelch Thresholds
⚫ Turn ON NetProtect UL PA Muting and Oscillation Detection for RU
devices.
Refer to section 3.28 through 3.36
19. Turn ON the RF Switches
⚫ Turn on Channel RF Switches
⚫ Turn on Main RF Switches
Refer to section 3.29
⚫ End of the Commissioning Process
3.6 V3 BBU – WAKE UP/TURN ON THE BATTERY
Before powering on the system, each BBU battery must be awakened/turned ON, so it is ready to use. This
allows the Battery Management System (BMS) to start up on battery power and be ready to communicate
with the charging system within the BDA/MU or RU.
• Push and hold the recessed RESET button located on top of the LiFEPO4 battery for approximately 3
seconds to wake up the battery. Once the SOC (State of Charge) LEDs begin to illuminate, release the
RESET button immediately (NOTE: Holding the RESET button longer than approximately 5 seconds will
cause the battery to go back into sleep mode. If this occurs, repeat the step to “wake-up” the battery).
See Figure 83 below.
