2.23 SYSTEM RF CONNECTIONS
The following RF connections should be completed before powering on the devices:
Table 7: System RF Connections Before Power Up
RF Connector
Descriptions
BDA/MU DT Port
Connect to the Donor Antenna feedline
BDA/MU MT Port
Connect to the Indoor Service Antenna feedline
BDA/MU UL Port
Connect to the FOU UL 1 if used in a fiber DAS configuration
BDA/MU DL Port
Connect to the FOU DL 1 if used in a fiber DAS configuration
BDA/MU DT Test
This port can be left unterminated. Use for live system DL/UL measurements
BDA/MU MT
Test
This port can be left unterminated. Use for live system DL/UL measurements
FOU UL 1
Connect to BDA/MU 1 UL Port if used in a fiber DAS configuration
FOU DL 1
Connect to BDA/MU 1 DL Port if used in a fiber DAS configuration
FOU UL 2
Connect to BDA/MU 2 UL Port if used in a fiber DAS configuration (Redundancy Feature)
FOU DL 2
Connect to BDA/MU 2 DL Port if used in a fiber DAS configuration (Redundancy Feature)
FOU UL_E
Connect to the next FOU UL 1 port if using expansion FOU(s)
FOU DL_E
Connect to the next FOU DL 1 port if using expansion FOU(s)
RU MT Port
Connect to the Indoor Service Antenna feedline
RU MT Test
This port can be left unterminated. Use for live system DL/UL measurements
ALERT! Disconnection of either of the RF ports (unloaded) may cause damage to the
equipment when power and equipment is active.
