1.10 V2 FOU RF AND FIBER SPECIFICATIONS
Frequency Band
MHz
758 - 869
Optical Wavelength Uplink
nm
1310
Optical Wavelength Downlink
nm
1550
Optical Connector Type
SC-APC
Optical Fiber Type
Single Mode, WDM (single strand of fiber per Remote Units)
End to End Optical Loss
dBo
 6.5
End to End Reflectance
dB
 -60
NOTE: All patch panels used between the Fiber Optic Unit and Remote Units must use SC/APC connectors or be fiber-sliced, no
LC/UPC connectors can be utilized in the fiber path between equipment
Number of RU supported per FOU
Up to 4 or 8 RU
Number of FOU supported per MU
Up to 4
1.11 V2 FOU MECHANICAL SPECIFICATIONS
Dimensions, H x W x D
in(mm)
18.5 x 15.8 x 3.4 (470 x 400 x 87)
Weight (without bracket)
4 Port
lb(kg)
25.4 (11.5)
8 Port
lb(kg)
27.6 (12.5)
Power Consumption (approx.)
4 Port
W
15
8 Port
W
20
Power Supply
VDC
+28 (From Master Unit)
Enclosure Cooling
Convection
Heat Dissipation
BTU/Hr
<35 (4 Port), <52 (8 Port)
Operating Temperature
o
F (
o
C)
-40 to +131 (-40 to +55)
Operating Humidity
 95%
Enclosure Class
UL50E Type 4 / NEMA 4
Note: Typical specifications at room temperature
