2.11 V3 BBU WALL MOUNTING
• If applicable, drill eight holes on the wall using the position of eight holes on the BBU mounting bracket
as a guide (BBU mounting bracket is built into the BBU cabinet).
• This step will require two people or special lifting equipment. Lift the BBU cabinet (Without Batteries)
into position and install the cabinet on the wall. It is recommended to use 3/8” x 1-1/2” lag screws and
fender washers when mounting to 3/4” fire treated plywood. If mounting to a concrete wall, DIN Rails, or
any other materials, refer to the local building code. Secure the BBU.
Figure 30: V3 BBU Wall Mounting
