1.29 V2 FOU CABINET DIMENSIONS
87 [3.4]
470 [18.5]
465 [18.3]
400 [15.7]
483 [19.0]
76 [3.0]
40 [1.6]
CriticalPoint
OP1 OP2
UL_E
UL1
DL_E
DL1
DL2
UL2
Figure 22: V2 FOU Cabinet Dimensions - Front, Side and Bottom View
