1.26 V3 BBU CABINET DIMENSIONS
605[23.8]
599[23.6]
500[19.7]
272.9[10.7]
302.9[11.9]
Figure 19: V3 BBU Cabinet Dimensions – Front, Side and Bottom View
2 x Door Latches
(Require Key)
