COMBA CriticalPoint V3 7 BDA - Page 216

CRITICALPOINT 700/800MHZ BDA/DAS/BBU V3 USER MANUAL
©2024 Comba Telecom. All Rights Reserved.
568 Gibraltar Drive, Milpitas, CA 95035 | +1 408 526 0180
Rev. 1-0-2 Rev. Date: 11-1-2024
Page: 216
Figure 191: Simulating Battery Charger Failure
If unit has a
cut-out section
of the cover
which exposes
the terminals,
you do not
need to remove
the cover.
Loosen the 4 screws with flathead
driver to remove the cover.
Remove this connector and wait
3-5 minutes for Battery Charger
Failure alarm
