CRITICALPOINT 700/800MHZ BDA/DAS/BBU V3 USER MANUAL
©2024 Comba Telecom. All Rights Reserved.
568 Gibraltar Drive, Milpitas, CA 95035 | +1 408 526 0180
Rev. 1-0-2 Rev. Date: 11-1-2024
Page: 34
Duplexer Part
Numbers*
Description
DU-78-V3S0
S0 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
DU-78-V3S1
S1 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
DU-78-V3S2
S2 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
DU-78-V3S3
S3 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
DU-78-V3S4
S4 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
DU-78-V3S5
S5 duplexer for V3 700/800MHz System, Order 2 per BDA or DAS Master Unit, Order 1 per DAS Remote Unit
*For Field Replacement Only
S2 S5 Duplexer
Part Numbers*
Description
V3S2-UPGRADE
Upgrade a S0/S1 700/800MHz BDA or Remote Unit with S2 duplexer, supports 700MHz NB only, high rejection
V3S3-UPGRADE
Upgrade a S0/S1 700/800MHz BDA or Remote Unit with S3 duplexer, supports 800MHz NB only, high rejection
V3S4-UPGRADE
Upgrade a S0/S1 700/800MHz BDA or Remote Unit with S4 duplexer, supports NPSPAC only, high rejection
V3S5-UPGRADE
Upgrade a S0/S1 700/800MHz BDA or Remote Unit with S5 duplexer, supports B14, 700MHz NB, 800MHz NB,
high rejection
*Production Lab upgrade for S0/S1 configuration units (order together with S0/S1 units ONLY)
FOU Part Numbers
Description
RHFOUV2F-E04UL
Critical Point Fiber Optical Unit for platform V2F and V3 NG, 4 port, UL 2524 Standard Certified
RHFOUV2F-E08UL
Critical Point Fiber Optical Unit for platform V2F and V3 NG, 8 port, UL 2524 Standard Certified
BBU Part Numbers
Battery Type
Capacity
Backup Hours
BBUV3-LFP48030
Lithium iron phosphate
30AH
>12H for 110W
BBUV3-LFP48060
Lithium iron phosphate
60AH
>24H for 110W, 12H for 220W
BBUV3-LFP48100
Lithium iron phosphate
100AH
>48H for 110W, 24H for 220W
BDA/Master Unit License
Part Numbers
Configuration
RX78V3-L-2733AASS
27dBm to 33dBm
upgrade license
27dBm to 33dBm upgrade license, for Single Band, Class A units
RX78V3-L-2733AADD
27dBm to 33dBm upgrade license, for Dual Band, Class A units
RX78V3-L-2733BBDD
27dBm to 33dBm upgrade license, for Dual Band, Class B units
RX78V3-L-3333AASD
Single Band to Dual
Band upgrade license
Single band to Dual Band upgrade license, for 33dBm, Class A units
RX78V3-L-3333BBSD
Single band to Dual Band upgrade license, for 33dBm, Class B units
RX78V3-L-2727AASD
Single band to Dual Band upgrade license, for 27dBm, Class A units
RX78V3-L-3333BASS
Class B to Class A
upgrade license
Class B to Class A upgrade license, for 33dBm, Single Band units
RX78V3-L-3333BADD
Class B to Class A upgrade license, for 33dBm, Dual Band units
RX78V3-L-2727BADD
Class B to Class A upgrade license, for 27dBm, Dual Band units
