3.3 Site Supervisor Housing Dimensions and Mounting
The Site Supervisor can be mounted to standard 35mm DIN rail using the orange mountain clips.
It can also be screwed to a back plate by pulling the four (4) orange mounting tabs out until they lock, which will expose
mounting holes.
Figure 3-2 - Site Supervisor Housing Dimensions and Mounting
