Copeland E3 - IPX 6 Relay; IPX 15 Relay; IPX 25 Relay; Supported Refrigerants

©2025 Copeland LP.
026-1803 R13 Supervisor I&O User Guide 9 - 65
9.47.1 IPX 6 Relay
The IPX 6 board provides expansion I/O for the Supervisory Controller.
Configurations and Specifications of IPX Devices:
9.47.2 IPX 15 Relay
The IPX 15 board provides expansion I/O for the Supervisory Controller.
Configurations and Specifications of IPX Devices:
9.47.3 IPX 25 Relay
The IPX 25 board provides expansion I/O for the Supervisory Controller.
Configurations and Specifications of IPX Devices:
9.48 Supported Refrigerants
The firmware supports many refrigerant types. The tables include dew (vapor), mid-point, and end-point curves.
Table 9-26 - Configurations and Specifications of IPX Devices
Name HW Format
Analog
Inputs
Digital
Inputs
Relays
Analog
Outputs
Connector Types Part Number
IPX106D
IPX206D
4 DIN Rail 7 3 6 3 Cable Harness
Connector Kit
817-7000
818-7001
Table 9-27 - Configurations and Specifications of IPX Devices
Name HW Format Analog Inputs Digital Inputs Relays Analog Outputs
IPX115D
IPX215D
10 DIN Rail 10 20 15 6
Table 9-28 - Configurations and Specifications of IPX Devices
Name HW Format
Analog
Inputs
Digital
Inputs
Relays
Analog
Outputs
Connector Types Part Number
IPX125D
IPX225D
10 DIN Rail 10 20 25 6 Cable Harness
Connector Kit
817-7002
818-7003
Table 9-29 - Legend
Key Description
No glide Single refrigerant or azeotropic blend
Mid-point (M) Uses mid-point between bubble and dew
End-point Shift (E) Uses end-point shift at 50 degrees F. Uses bubble above 50 and dewpoint at or below 50
Bubble (B) Bubble (Liquid)
Dew (D) Dew (Vapor)
