7.2.3.7 Real Time Clock Updates
Current system date or time is sent to the RTU board
periodically with a 10-second interval.
7.2.3.8 Hand-Held Terminal Support
1. You can connect to the RTU board with a hand-held
terminal (HHT) to read or write the configuration of this
RTU board.
2. When a HHT is connected to a RTU board, any setpoint
change made from UI will not be sent to the RTU board.
Some controllers will accept the changes but some will
not.
3. The Supervisory Controller downloads all setpoints and
configuration parameters you changed from UI upon
receipt of a message from the RTU that the hand-held
terminal is disconnected. This will overwrite any changes
made using the HHT.
4. The Supervisory Controller does not accept permanent
changes made via the hand-held terminal to the
Supervisory Controller.
7.2.4 MultiFlex RCB Support
7.2.4.1 I/O Network and MultiFlex RCB
Setup on Serial Port
1. Navigate to serial port configuration screen, select an
unused port and configure it as an I/O network port.
2. Configure the baud rate of the I/O network port, then
select MultiFlex RCB from the supported board types for
this port. Set the number of board needed to setup, click
Save to add the RCB devices. RCB board status will
appear Online.
3. Navigate to the “HVAC - RCB_0X” device status screen
through the site map, the status screen displays the
following sections:
• General
• Alarm Outs
• Inputs
• Outputs
• RCB Outputs
4. Click Details on the status screen, the system will display
the properties of the RCB board by the properties group.
You can now view and configure the properties of the
RCB board.
5. After configuring the properties, the new values can be
sent to RCB application on the Supervisory Controller
and RCB board on the I/O network. The RCB board can
now work correctly on the controller.
7.2.4.2 Creating an Instance of RCB
Application
You can create an instance of RCB application even if the
RCB board is not connected to the Supervisory Controller,
however the board status is displayed “Offline”.
If the RCB board is connected to the supervisory controller
through the I/O network, the supervisory controller should
find the RCB board and its property values and should be
read on the controller through the I/O network.
7.2.4.3 Deleting/Checking Status of RCB
Board
You can navigate to Network Summary screen to do the
following operations:
1. View all the devices connected to the Supervisory
Controller from the I/O network and its online status.
2. Delete a device.
3. View the I/O network traffic status.
4. Navigate to the summary screen of a specific device.
7.2.4.4 Zone Management
You can associate an RCB board with a zone.When an RCB
board is associated with a zone, some inputs of RCB should
use the output values from zone. The are the property
mapping list you can use:
Table 7-4- RCB and Zone Property Mapping List
RCB Inputs Zone Outputs
OCC STATE ZONE_OCC_STATE
ZONE TEMP ZONE_TEMP_OUT
ECON OK ZONE ECON OK
DEHUM ACTIVE ZONE DEHUM ACTIVE
OCC HEAT ZONE HEAT OCC OUT
UNOCC HEAT ZONE HEAT UOC OUT
OCC COOL ZONE COOL OCC OUT
UNOCC COOL ZONE COOL UOC OUT
OCC DEHUM ZONE FB HUMID STPT
SEASON ZONE_SUM_WIN_MODE_OUT
UNOCC DEHUM ZONE_DEHUM_UNOC_OUT
OCC HUMIDITY ZONE_FB_HUMID_STPT
UNOCC HUMIDITY ZONE_HUM_OUT
