9 Software Overview
9.1 Supervisory Controller Application and System Capacity Matrix
Customers are cautioned that the figures in each cell of the following tables may only be interpreted as a general
rule-of-thumb number. Values, where appearing in any cell, are intended to represent the designated maximum number for
particular application types (as shown in rows) for each Supervisory Controller model/series (as shown in columns), but
independent of other application types. In other words, these figures are not indicative of the maximum number of combined
applications that can be read by a single Supervisory Controller.
The Supervisory Controller is designed (and required) to handle a combination of multiple applications at the same time. The
extent of such combinations that can be added to each Supervisory Controller should only be determined by a qualified
Copeland support specialist and will be governed by customized store requirements. In general, just as with computers, each
additional input/memory requirement imposed on the Supervisory Controller would reduce the memory available for other
applications.
Table 9-1 - Supervisory Controller Application and System Capacity Matrix
Application
Supervisor
Small
Format SF
Refrigeration
Supervisor
RXS
Refrigeration
Supervisor
Expanded
*
RXe
Building
Supervisor
BXS
Building
Supervisor
Expanded
*
BXe
Combination
Supervisor
CXS
Combination
Supervisor
Expanded
*
CXe
Service
Replacement
SR
Site
Aggregator
SA
CO2-CXe
CO2-
RXe
Email and Text
Alarms
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Graphical Defrost
Summary
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
File Management ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Site Inventory ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Duplicate
Application
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Customer Roles and
Permissions
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Custom Summary
Screens
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Ethernet, 3 Ports ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
USB, 2 Ports ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
SD, 1 Port, 1 GB
Provided
✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
Site Aggregator * * * * * * * * ✔ - -
Smart Alarms * * * * * * * * ✔ - -
Performance Meter * * * * * * * * ✔ - -
Floor Plan ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ - -
AHU Large - - - 6 8 6 8 9 - 8 0
AHU Small 4 - - - - - - - - - -
Analog Combiner 64 128 128 128 128 128 128 130 - 128 128
Analog Sensor
Control
12 64 72 64 72 24 48 80 - 72 72
Anti-Sweat 4 16 64 16 48 8 16 70 - 16 64
Case Control Circuit - 48 64 - - 12 24 70 - 24 64
CO2 Suction Group - - - - - - - - - 3 3
Condenser - 1 2 - - 1 2 2 - 2 2
CoreSense (Comm) - - - 31 31 31 31 40 - 2 2
