026-1803 R13 Supervisor I&O User Guide 8 - 2
8.1.2 Specifications
8.1.3 Mounting Dimensions
Table 8-1 - Product Specifications
10.1-Inch Display for Site Supervisor
Screen Size 10.1-Inch
Screen Type Capacitive Multi-Touch
Resolution 1280 x 800
Material ABS Black
Mounting Type 75mm x 75mm Mount
CPU 1.8 GHZ quadcore
Memory RAM 2GB, HDD 16GB
Network 1 RJ54 Ethernet Port
WIFI Optional
Bluetooth Optional
Unit Size 10.257” x 7.029” x 1.004” (260.54mm x 178.54mm x 25.50mm)
Rating Commercial
Temp Rating -4°F to 140°F (-20°C to 60°C)
Power Supply 12VDC 2A max
Figure 8-3 - 75mm x 75mm Mount
