026-1803 R13 Supervisor I&O User Guide 9 - 3
*
License available.
**
The number of suction groups indicated equals the total number of combined suction groups allowed. Both Enhanced and Standard suction groups
combined cannot exceed this number.
**
The number shown for Supervisory controllers indicates the total number of Suction Group applications available. A controller can support any combination of
standard Suction Groups and Enhanced Suction Groups that do not exceed the total number for either type. For example, an RX supports two (2) Enhanced
Suction Controls and two (2) Standard Suction Controls (a total of 4) or three (3) Enhanced Suction Controls and one (1) Standard Suction Control (a total of 4).
Supervisor I/O Network (RS-485)
Specified wiring: Belden #8761 (non-plenum), Belden #82761 and #88761 (plenum).
Standard Suction
Control**
- 4 4 - - 1 4 5 - - -
TD Condenser Fan
Control
- 64 64 16 28 16 28 70 - 28 64
Time Schedule 8 64 64 64 64 16 32 70 - 64 64
Utility Monitoring 8 16 16 32 64 8 16 35 - 64 64
Wireless Gateway 1 1 1 1 1 1 1 1 - 1 1
Wireless Module 99 99 99 99 99 99 99 99 - - -
ECB-VAV - - - 25 25 25 25 - - 25 0
Table 9-2 - Supervisory Controller I/O Network RS-485
Application
Supervisor
Small Format
SF
Refrigeration
Supervisor
RXS
Refrigeration
Supervisor
Expanded
*
RXe
Building
Supervisor
BXS
Building
Supervisor
Expanded
*
BXe
Combination
Supervisor CXS
Combination
Supervisor
Expanded
*
CXe
Service
Replacement
SR
4AO 2 16 16 16 16 16 16 16
8RO 16 32 32 32 32 32 32 32
8DO 4 16 16 16 16 16 16 16
16AI 16 16 16 16 16 16 16 16
MultiFlex
CUB
- 31 31 - - - 31 31
MultiFlex ESR - 31 31 - - 31 31 31
MultiFlex
RCB
- - - 64 64 32 64 64
MultiFlex
RTU/ARTC
- - - 32 32 32 32 32
Table 9-1 - Supervisory Controller Application and System Capacity Matrix
Application
Supervisor
Small
Format SF
Refrigeration
Supervisor
RXS
Refrigeration
Supervisor
Expanded
*
RXe
Building
Supervisor
BXS
Building
Supervisor
Expanded
*
BXe
Combination
Supervisor
CXS
Combination
Supervisor
Expanded
*
CXe
Service
Replacement
SR
Site
Aggregator
SA
CO2-CXe
CO2-
RXe
