FIP Snooping | 203
Figure 10-12 shows how to configure FIP snooping on FCoE VLAN 10, an FCF-facing port (0/50), and an
ENode server-facing port (0/1), and to configure the FIP snooping ports as tagged members of the FCoE
VLAN enabled for FIP snooping.
Figure 10-12. FIP Snooping Configuration Example
After FIP packets are exchanged between the ENode and the switch, a FIP snooping session is established.
ACLS are dynamically generated for FIP snooping on the FIP snooping bridge/switch.
Enable the FIP snooping feature on the switch (FIP snooping bridge):
FTOS(conf)# feature fip-snooping
Enable FIP snooping on FCoE VLAN 10:
FTOS(conf)# interface vlan 10
FTOS(conf-if-vl-10)# fip-snooping enable
Enable an FC-MAP value on VLAN 10:
FTOS(conf-if-vl-10)# fip-snooping fc-map 0xOEFC01
Note: Configuring an FC-MAP value is only required if you do nto use the default FC-MAP value (0x0EFC00).
Configure the ENode server-facing port:
FTOS(conf)# interface tengigabitethernet 0/1
FTOS(conf-if-te-0/1)# portmode hybrid
FTOS(conf-if-te-0/1)# switchport
Note: A port is enbled by default for bridge-ENode links.
Configure the FCF-facing port:
FTOS(conf)# interface tengigabitethernet 0/50
FTOS(conf-if-te-0/50)# portmode hybrid
FTOS(conf-if-te-0/50)# switchport
FTOS(conf-if-te-0/50)# fip-snooping port-mode fcf
Configure FIP snooping ports as tagged members of FCoE VLAN:
FTOS(conf)# interface vlan 10
FTOS(conf-if-vl-10)# tagged tengigabitethernet 0/1
FTOS(conf-if-vl-10)# tagged tengigabitethernet 0/50
FTOS(conf-if-te-0/1)# no shut
FTOS(conf-if-te-0/50)# no shut
FTOS(conf-if-vl-10)# no shut
