226 | Interfaces
www.dell.com | support.dell.com
To assign an IP address, use the following commands in INTERFACE mode:
You can only configure one (1) primary IP address per interface. You can configure up to 255 secondary
IP addresses on a single interface.
To view all interfaces with an IP address assigned, use the
show ip interfaces brief command in EXEC mode.
To view IP information on an interface in Layer 3 mode, use the
show ip interface command in EXEC
Privilege mode (Figure 13-7).
Figure 13-7. show ip interface Command Example
Management Interfaces
The IOM management interface has both a public IP and private IP address on the internal Fabric D
interface. The public IP address is exposed to the outside world for Web GUI configurations/WSMAN and
other proprietary traffic. You can statically configure the public IP address or obtain the IP address
dynamically using the dynamic host configuration protocol (DHCP).
Command Syntax Command Mode Purpose
no shutdown
INTERFACE Enable the interface.
ip address ip-address mask [secondary]
INTERFACE Configure a primary IP address and mask on
the interface. The ip-address must be in
dotted-decimal format (A.B.C.D) and the
mask must be decimal and should be
mentioned in slash format (/xx).
Add the keyword secondary if the IP address
is the interface’s backup IP address.
Note: When you shut down a management interface, connectivity to the interface's private IP address is
disabled.
FTOS(conf-if-vl-10)#do sh int vl 10
Vlan 10 is up, line protocol is up
Address is 00:1e:c9:f1:03:38, Current address is 00:1e:c9:f1:03:38
Interface index is 1107787786
Internet address is 5.5.5.1/24
Mode of IP Address Assignment : MANUAL
DHCP Client-ID: vlan10001ec9f10338
MTU 1554 bytes, IP MTU 1500 bytes
LineSpeed 1000 Mbit
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 00:01:09
Queueing strategy: fifo
Time since last interface status change: 00:00:46
