Dell Force10 MXL Blade Configuration Guide

502 | Security
www.dell.com | support.dell.com
Figure 28-17. Example Access Class Configuration Using TACACS+ Without Prompt
VTY MAC-SA Filter Support
FTOS supports MAC access lists which permit or deny users based on their source MAC address. With
this approach, you can implement a security policy based on the source MAC address.
To apply a MAC ACL on a VTY line, use the same
access-class command as IP ACLs (Figure 28-18).
Figure 28-18 shows how to deny incoming connections from subnet 10.0.0.0 without displaying a login
prompt.
Figure 28-18. Example Access Class Configuration Using TACACS+ Without Prompt
FTOS(conf)#ip access-list standard deny10
FTOS(conf-ext-nacl)#permit 10.0.0.0/8
FTOS(conf-ext-nacl)#deny any
FTOS(conf)#
FTOS(conf)#aaa authentication login tacacsmethod tacacs+
FTOS(conf)#tacacs-server host 256.1.1.2 key FTOS
FTOS(conf)#
FTOS(conf)#line vty 0 9
FTOS(conf-line-vty)#login authentication tacacsmethod
FTOS(conf-line-vty)#
FTOS(conf-line-vty)#access-class deny10
FTOS(conf-line-vty)#end
(same applies for radius and line authentication)
FTOS(conf)#mac access-list standard sourcemac
FTOS(conf-std-mac)#permit 00:00:5e:00:01:01
FTOS(conf-std-mac)#deny any
FTOS(conf)#
FTOS(conf)#line vty 0 9
FTOS(conf-line-vty)#access-class sourcemac
FTOS(conf-line-vty)#end

Dell Force10 MXL Blade Specifications

General

Switching Capacity	1.28 Tbps
Forwarding Rate	952 Mpps
Product Type	Blade Switch
Latency	< 3 microseconds
Operating Temperature	0°C to 40°C (32°F to 104°F)
Redundancy	Yes
Management	CLI, SNMP, Web
Layer Support	Layer 2, Layer 3
Jumbo Frame Support	Up to 9216 bytes
Management Ports	1 x 10/100/1000 Mbps
Storage Temperature	-40°C to 70°C
Weight	4.5 kg (9.9 lbs)
