Access Control Lists (ACLs) | 95

Configure Route Map Filters

Within ROUTE-MAP mode, there are match and set commands. match commands search for a certain

criterion in the routes and

set commands change the characteristics of those routes, either by adding

something or by specifying a level.

When there are multiple

match commands of the same parameter under one instance of a route-map, FTOS

does a match between either of those match commands. If there are multiple

match commands of different

parameter, FTOS does a match ONLY if there is a match among ALL match commands. Refer to the

following examples:

Example 1

In the above route-map, if a route has any of the tag value specified in the match commands, there is a

match.

Example 2

In the above route-map, only if a route has both the characteristics mentioned in the route-map, it is

matched. Explaining further, the route must have a tag value of 1000 and a metric value of 2000. Only then

there is a match.

Also, if there are different instances of the same route-map, it is sufficient if a permit match happens in any

instance of that route-map, for example:

In the above route-map, instance 10 permits the route having a tag value of 1000 and instances 20 and 30

denies the route having a tag value of 1000. In the above scenario, FTOS scans all the instances of the

route-map for any permit statement. If there is a match anywhere, the route is permitted, though other

instances of the route-map denies it.

FTOS(conf)#route-map force permit 10
