Dell Force10 MXL Blade - Configuration Mode

Access Control Lists (ACLs) | 77
Figure 5-6. Command Example: show ip accounting access-list
Figure 5-7 shows how the seq command orders the filters according to the sequence number assigned. In
the example, filter 25 was configured before filter 15, but the
show config command displays the filters in
the correct order.
Figure 5-7. Command example: seq
To delete a filter, use the no seq sequence-number command in IP ACCESS LIST mode.
If you are creating a standard ACL with only one or two filters, you can let FTOS assign a sequence
number based on the order in which the filters are configured. The software assigns filters in multiples of 5.
To configure a filter without a specified sequence number, follow these steps starting in
CONFIGURATION mode:
Step Command Syntax Command Mode Purpose
1 ip access-list standard access-list-name CONFIGURATION Create a standard IP ACL and assign it a
unique name.
2
{deny | permit} {source [mask] | any |
host
ip-address} [count [byte]] [order]
[fragments]
CONFIG-STD-NACL Configure a drop or forward IP ACL filter.
FTOS#show ip accounting access ToOspf interface tengig 1/6
Standard IP access list ToOspf
seq 5 deny any
seq 10 deny 10.2.0.0 /16
seq 15 deny 10.3.0.0 /16
seq 20 deny 10.4.0.0 /16
seq 25 deny 10.5.0.0 /16
seq 30 deny 10.6.0.0 /16
seq 35 deny 10.7.0.0 /16
seq 40 deny 10.8.0.0 /16
seq 45 deny 10.9.0.0 /16
seq 50 deny 10.10.0.0 /16
FTOS#
FTOS(conf-std-nacl)#seq 25 deny ip host 10.5.0.0 any
FTOS(conf-std-nacl)#seq 15 permit tcp 10.3.0.0 /16 any
FTOS(conf-std-nacl)#show config
!
ip access-list standard dilling
seq 15 permit tcp 10.3.0.0/16 any
FTOS(conf-std-nacl)#
