Quality of Service (QoS) | 433

Display WRED Drop Statistics

To display the number of packets FTOS dropped by the WRED profile, use the show qos statistics command

from EXEC Privilege mode (Figure 24-13).

Figure 24-13. show qos statistics Command Example

FTOS#show qos statistics wred-profile

Interface Te 0/20

Drop-statistic Dropped Pkts

Green 11234

Yellow 12484

Out of Profile 0

FTOS#
