VRRP Configuration
By default, VRRP is not configured.
Configuration Task List for VRRP
The following list specifies the configuration tasks for VRRP:
• Create a Virtual Router (mandatory)
• Assign Virtual IP addresses (mandatory)
• Set the VRRP Group (Virtual Router) Priority (optional)
• Configure VRRP Authentication (optional)
• Disable Preempt (optional)
• Change the Advertisement Interval (optional)
• Track an Interface or Object (optional)
• VRRP Initialization Delay
For a complete listing of all commands related to VRRP, refer to FTOS Command Line Interface Guide.
Create a Virtual Router
To enable VRRP, you must create a virtual router. In FTOS, a VRRP group is identified by the virtual
router identifier (VRID).
To enable a virtual router, use the following command in INTERFACE mode (Figure 38-2). To delete a
VRRP group, use the
no vrrp-group vrid command in INTERFACE mode.
Figure 38-2. vrrp-group Command Example
Task Command Syntax Command Mode
Create a virtual router for that interface
with a VRID.
VRID Range: 1 to 255
vrrp-group vrid INTERFACE
Note: The interface must already have a Primary IP Address defined and
be enabled.
FTOS(conf)#int tengig 1/1
FTOS(conf-if-te-1/1)#vrrp-group 111
FTOS(conf-if-te-1/1-vrid-111)#
Virtual Router ID
and VRRP Group identifier
