420 | Quality of Service (QoS)
www.dell.com | support.dell.com
Configure Port-based Rate Shaping
Rate shaping buffers, rather than drops, traffic that exceeds the specified rate until the buffer is exhausted.
If any stream exceeds the configured bandwidth on a continuous basis, it can consume all of the buffer
space that is allocated to the port.
• To apply rate shaping to outgoing traffic on a port, use the
rate shape command from INTERFACE
mode (Figure 24-5).
• To apply rate shaping to a queue, use the
rate-shape command from QoS Policy mode.
Figure 24-5. Applying Rate Shaping to Outgoing Traffic
Policy-Based QoS Configurations
Policy-based QoS configurations consist of the components shown in Figure 24-6.
Figure 24-6. Constructing Policy-based QoS Configurations
FTOS#config
FTOS(conf)#interface tengigabitethernet 1/0
FTOS(conf-if)#rate shape 500 50
FTOS(conf-if)#end
FTOS#
